Product Parameters
|
Model |
HL560 |
HL700 |
HL850 |
|
Power (KW) |
132 |
160 |
220-250 |
|
Speed(r/min) |
1450 |
1450 |
1450 |
|
Power Supply Voltage |
380v/50hz/3phase |
380v/50hz/3phase |
380v/50hz/3phase |
|
Die Diameter (mm) |
548 |
700 |
850 |
|
Finished Product Size (mm) |
6-12 |
6-12 |
6-12 |
|
Feeding Temperature(°C) |
100-150 |
100-150 |
100-150 |
|
Raw material moisture (%) |
10-15 |
10-15 |
10-20 |
|
Hourly output (T/H) |
1.5-2 |
2-2.5 |
3-4 |
|
Feeding power (KW) |
2.2 |
2.2 |
3 |
|
Oil pump power (KW) |
0.37 |
0.37 |
0.75 |
|
Weight (T) |
5 |
6.5 |
10-12 |
|
Dimensions (mm) |
2600*1300*1800 |
2900*1800*1900 |
3000*1600*2200 |
Product Features and Applications
Vertical, static mold installation, double-layer design for both upper and lower use
Patented gearbox, changing the transmission method and facilitating maintenance
The gearbox and pellet mill main unit are integrated, allowing the oil in the gearbox to be recycled through the pellet mill body
Product Details
01.
Vertical mold orientation, vertical feeding, no arching, easy heat dissipation
02.
The gearbox uses high-quality alloy steel internally, with an increased gear module, reducing the failure rate
03.
The biomass pellet mill has two lubrication systems for smoother cleaning
Product Supporting(certificates, factory video)
Product Supporting(certificates, factory video)
FAQ
1) What is the minimum moisture content of the raw materials for a biomass pellet making machine?
A: Standard moisture content control for raw materials: Wood chips: optimal 12%–15%, generally within the acceptable range of 8%–18%; Straw and rice husks: optimal 10%–13%
2)Why are the pellets loose, crumble easily when squeezed, and not hard?
A: ①Imbalanced moisture content in the raw materials
②Excessive gap between the die rollers
③Mismatched ring die compression ratio
④Wear and slippage of the pressure rollers
3) Can the pellet size produced by the pellet mill be adjusted?
A: The output pellet size can be freely adjusted
4)What is the hourly output of the pellet mill?
A: The output of the pellet mill is determined by its power
5)Can the power supply voltage be customized?
A: Overseas power supply voltage and frequency can be customized
6)Can the die diameter be customized?
①The overall installation reference diameter of the outer ring die (die outer diameter, mounting position) cannot be customized or changed.
②All internal parameters of the ring die can be customized as needed
