Product Parameters
|
Name |
Bearing for wood chipper |
|
Inner Diameter (mm) |
110 |
|
Outer Diameter (mm) |
240 |
|
Thickness (mm) |
80 |
|
Rated Dynamic Load (KN) |
795 |
|
Rated Static Load (KN) |
998 |
|
Limited Permissible Speed (r/min) |
1450 |
Product Features and Applications
Utilizes a triple-layer composite seal, effectively preventing dust, water, and sawdust intrusion, and eliminating corrosion of the rubber rings or iron sheets inside the bearing
Long-term lack of lubrication in the wood chipper bearings can cause raceway scoring, bearing seizure, dry friction, and high temperatures
Primarily used in biomass power plants, wood chip trading and recycling companies, engineered wood products factories, and reforestation projects
Product Details
01.
Wood chipper bearing seal is made of thickened fluorine rubber oil seal, resistant to dust, mud, and high temperatures
02.
The clearance between the bearing housing and the outer ring of the bearing is standard, ensuring no play or jamming during operation
03.
The bearing models of the left and right end cutter rollers are completely identical and interchangeable
Product Certification
After-Sales Service
Bearing for wood chipper is consumable parts and are not covered by after-sales warranty
FAQ
1)Are the cutter roller bearings, feed roller bearings, and discharge roller bearings of a wood chipper interchangeable?
A: Most models of these three types are not directly interchangeable
2)Can ordinary national standard bearings replace the special cutter roller bearings for wood chippers?
A: It is not recommended to use ordinary national standard deep groove ball bearings to replace the special self-aligning roller bearings for cutter rollers, as the risk is extremely high
3)What are the installation steps for the cutter roller bearings of a wood chipper?
A: Safety precautions → Remove the old bearing → Pre-treat the new bearing → Heat-install the bearing (optimal solution) → Assemble the sealing components → Adjust the clearance → Test run
4)What causes the wood chipper to jam or stop turning after replacing the bearings?
A: ①Incorrect bearing installation direction
②Over-fitting with excessive force
③Misalignment of the bearing housings at both ends
5) What causes the bearings to break and the rollers to scatter after a short period of use?
A: ① Incorrect selection
②Forced installation
③ Wood chips and mud intrusion
6) How can I prevent sawdust and mud from easily entering the bearing?
A: ①Multiple seal upgrades
②Optimized lubrication structure
③Physical shielding under on-site conditions
④Regular inspection and maintenance
