Product Parameters
|
Model |
HL3600 |
HL3300 |
|
Discharge Conveyor Belt Width (mm) |
1200 |
1200 |
|
Discharge Conveyor Belt Speed (m/min) |
165 |
165 |
|
Discharge Height (mm) |
4500 |
4500 |
|
Number of Discharge Motors (piece) |
1 |
1 |
|
Output (T/H) |
20-40 |
10-20 |
|
Maximum Processing Diameter (mm) |
2400 |
2000 |
|
Dimensions (mm) |
7800*3600*3700 |
7000*3200*3500 |
Product Features and Applications
Uses a hydraulic circular inlet feeder, paired with 6-10mm high-manganese steel plates, providing strong load-bearing capacity
Dedicated heavy-duty crushing chamber, widened and deepened for one-time feeding of large pieces of material, resulting in higher production capacity
Primarily used in construction waste recycling companies, demolition sites, and waste wood recycling traders
Product Details
01.
Heavy-duty welded and dynamically balanced cutting rollers for low vibration during operation
02.
Available in fixed motor and mobile diesel engine versions, offering variety to suit different customers
03.
Standard configuration includes pressure-sensing automatic reverse rotation and automatic material discharge in case of jamming, eliminating the need for manual cleaning
Product Supporting Documents (Upload Certificates/Images)
After-Sales Service (Videos or Photos)
FAQ
1) Should I choose a stationary motor version, a tire-tractor version, or a tracked diesel engine version for the template crusher?
A: The choice depends on the location of the formwork raw materials. If the raw materials are in a fixed factory, choose the fixed motor version; if the raw materials are on a smooth, moving surface at the construction site, choose the tire-tractor diesel engine version; if there are many miscellaneous formwork materials on a muddy or complex construction site, choose the tracked diesel engine version
2)Can it crush template without an iron removal device?
A: It can, but continuous processing without a metal removal device is not recommended
3)What is the hourly output?
A: It depends on the thickness of the formwork, whether it contains a large number of nails, and whether it is continuously fed
4)How often should the machine's hammers or cutting tools be sharpened or replaced?
A: Most formwork crushers use alloy steel hammers (hammer-type), and a few high-powered models use heavy-duty cutting tools
5)What are the advantages and disadvantages of a template crusher compared to a regular log chipper?
A：Advantages:
1. Impact resistant, specifically designed for construction formwork containing nails and concrete lumps
2. Higher rotor structural strength, resistant to hard object impacts, less prone to jamming
3. Wide feed inlet, allowing direct feeding of entire stacks of formwork without cutting
Disadvantages:
1. Greater overall weight and higher purchase price than ordinary wood chippers
2. Higher energy consumption and faster blade wear
3. Output particles are relatively fine, unable to produce regular industrial wood chips
6) Can it simultaneously crush template, branches, and straw?
A: Yes, it can be mixed and crushed in one unit, which is a standard compatible material for this model
