Product Parameters
|
Model |
HL3600 |
HL3300 |
|
Discharge Conveyor Belt Width (mm) |
10000 |
10000 |
|
Discharge Conveyor Belt Speed(m/min) |
165 |
165 |
|
Discharge Height (m) |
4.5 |
4.5 |
|
Number of Discharge Motors (piece) |
1 |
1 |
|
Hydraulic System |
Hydraulic Tank Capacity: 450L 24V Solenoid Valve Remote Control |
Hydraulic Tank Capacity: 450L 24V Solenoid Valve Remote Control |
|
Control System |
Remote Control, Frequency Conversion |
Remote Control, Frequency Conversion |
|
Output (T/H) |
20-40 |
10-20 |
|
Engine Manufacturer |
Steyr |
Steyr |
|
Dimensions (mm) |
7800*3600*3700 |
7000*3200*3500 |
Product Features and Applications
Fixed disc wood chipper is equipped with a hydraulic oil filter, making the machine more stable in operation
The engine water tank fan has an adjustable angle for cleaning the water tank
High-power motor, high safety, a good helper for processing wood
Product Details
01.
Fixed disc wood chipper is equipped with a pure electric motor drive, a high-power power system, and a reducer for forced feeding
02.
It adopts a combination of a large-diameter disc rotating hopper and a multi-layer alloy cutting disc, resulting in high efficiency and good-looking chip shape.
03.
The electrical control system uses a PLC frequency converter control cabinet, with automatic reverse rotation when jammed and overload shutdown protection, improving safety and efficiency
Product Supporting (Certificates/Pictures)
After-Sales Service (Videos/Photos)
FAQ
1) What is the diameter of the fixed disc crusher?
A: The diameter of the HL3600 is 2400mm, and the diameter of the HL3300 is 2000mm
2)Can the width of the discharge conveyor belt be customized?
A: Yes, it can be customized
3)What is the fuel consumption of a stationary crusher?
A: Fuel consumption is related to output. The hardness of the material and the feed rate will also affect the actual fuel consumption
4)Can the engine brand be changed?
A: Yes, the brand can be changed
5)What is the disc depth of a fixed disc crusher?
A: The disc depth is 1500mm
6)Can a fixed disc crusher be converted into a mobile disc crusher later?
A: Later conversion is not recommended. It is difficult and requires reinforcing the frame, adding counterweights, adding a chassis, and a hydraulic walking system, etc
