Product Parameters
|
Name |
Conveyor belt for wood chipper |
|
Width (mm) |
400/500/650/800/1000/1200 |
|
Thickness (mm) |
8-10/10-12/12-15 |
|
Suitable Material Moisture Content (%) |
8-60/60-100 |
|
Belt Running Speed (m/s) |
0.12-0.25/0.1-0.3/0.08-0.35 |
|
Incline Angle (°) |
≤15/≤18/≤22 |
Product Features and Applications
Features elastic cushioning to prevent instantaneous torsion damage to the motor shaft, locking sleeve, and main shaft
The belt should not loosen easily, so avoid frequent machine stops to tighten it, reduce maintenance time, and improve efficiency
Suitable for outdoor rain, high summer temperatures, and low winter temperatures; does not easily harden or crack
Product Details
01.
The belt has an anti-slip effect, easily handling wet materials without slippage or deviation, requiring no manual assistance
02.
The overall weight is significantly lower than a chain-plate feeding system, with minimal metal-on-metal noise during belt operation
03.
The belt speed is uniform, producing clean chips, and belt replacement is relatively easy
Product Supporting Documents
After-Sales Service
Conveyor belt for wood chipper is a wear part and there is no after-sales service
FAQ
1)What causes frequent misalignment of the belt-fed conveyor?
A:①The head and tail roller shafts are not parallel.
②The idler roller brackets are misaligned, or some idlers are stuck and not rotating.
③The material drop point consistently deviates to one side of the belt
2) How can we prevent frequent tearing and rapid wear of the belt edges?
A: ①Correct the overall machine level and roller parallelism.
②Install a guide baffle at the head discharge port.
③Install anti-deviation vertical rollers on both sides for limiting belt misalignment
3) What is the normal service life of a belt?
A: For ordinary rubber flat belts, under light load conditions with dry wood chips: 800-1500 hours
4)What causes the belt to frequently slip, overheat, and smoke?
A: ①Insufficient tension of the tension screw
②Oil, water, or wood chip powder contamination on the roller surface
③Sudden overload of the equipment, with the instantaneous torque exceeding the belt drive load
5) What can be done if the belt hardens and becomes prone to slipping and cracking in low winter temperatures?
A: ①Replace with a cold- and low-temperature resistant conveyor belt
②Run the equipment unloaded for 10 minutes before starting
③Increase the belt tension appropriately
6) Is it better to choose a belt-fed or chain-plate-fed conveyor?
A: Use a belt for conveying fine, crushed materials at the rear; use a chain conveyor for heavy-duty, coarse materials at the front, or in harsh working conditions
